Ultra-high-speed digital micromirror spatial light modulator DMD-1K070-01-16HS

Product Features:

1.Adopt TI advanced optical control chip

2.Designed for industrial and scientific research fields

3.Support precise internal and external synchronization signals

4.Able to work closely with the camera

    Product Parameters

    Model Number

    DMD-1K070-01-16HS

    Specificities

    ultra high speed

    Resolution

    1024×768

    Pixel Size

    13.68μm

    Image Size

    0.7"

    Depth

    1-16 bit adjustable

    Contrast Ratio

    >2000:1

    Refresh Frequency

    (real time transmission)

    8 Bit

    /

    Input-output synchronization

    Support

    Refresh Frequency

    (thumbnail sketch)

    16 Bit

    3Hz (5us minimum)

    Spectral Range

    363nm-420nm

    8 Bit

    657.56Hz (5us minimum)

    Reflectivity

    >78.5%

    6 Bit

    /

    Damage Threshold

    10W/cm²

    1 Bit

    27995Hz (5us interval)

    RAM/Flash

    RAM 16GB

    Real-time transmission video interface

    NO

    PC Interface

    Gigabit Ethernet interface (with USB3.0 adapter)

    Number Of Maps Stored

    174762 (1 BIT)

    21845(8 BIT)

    Angle Of Divergence

    ±12°

    Control  Software

    HS_DMD_Control

    Supporting software

    10v1

    1. Supports high-speed display of binary images, eight-bit grayscale images, sixteen-bit grayscale images and other 16 grayscale levels, and the image grayscale level can be set flexibly. 2.

    2. The cycle display period can be customized, and the frequency can be changed by changing the length of the corresponding cycle time.

    3. When the cycle is displayed, you can “terminate” the playback, and change the display cycle and playback order set before.

    4. Support internal and external cycle playback and single cycle playback, support internal and external synchronization trigger.

    5. Adopts Gigabit Ethernet interface for communication, and USB3.0 network card can also be used for working, which is easy and flexible to use.

    6. Supports multiple device networking and synchronized work.

    Areas of application

    • Laser direct imaging
    • holographic imaging
    • optical field modulation
    •  machine vision
    • vision guidance
    • computational imaging
    • spectral analysis
    • biomicrography
    • circuit board exposure
    • structured light projection
    • laser holography
    • maskless lithography
    • hyperspectral imaging
    • laser beam calibration
    • 3D measurement and 3D printer technology
    • spectral analysis
    • simulators
