Reflective phase type spatial light modulator FSLM-2K70-P03/04HR

Functional Features：

1.Distinguishes between four bands for use: 400nm-700nm, 450nm-1100nm, 1000nm-1100nm, and 1500nm-1700nm;

2.Low price and high cost performance ratio;

3.The HR series can be used in laser processing with an optical utilization rate of up to 85%;

4.The most versatile pixel size of 8 μm is available;

5.Flexible and synchronized triggering.

product details

Product Parameters

Model Number	FSLM-2K70-P03/04HR	Modulation Type	Phase Type
LCOS type	Reflection	Grayscale Level	8 bit, 256 step
Resolution	1920×1080	Image Size	8.0μm
Effective area	0.69" 15.36mm×8.64mm	Modulation depth	2π@1064nm Max：3.5π 2π@1550nm Max：2.3π
Fill factor	87%	Optical Utilization	85%@1064nm 85%@1550nm
Gamma calibration	Support	Phase calibration	Support
Power input	5V 3A	Response time	≤100ms
Refresh frequency	60Hz	Spectral range	1000nm-1100nm 1500nm-1700nm
Damage Threshold	≤30W/cm²(no water cooling) ≤150W/cm²(water cooling)	Data Interface	DVI / HDMI

Supporting software

1. Based on C/C++ development, running environment: Windows7 Sp1 and above, 32bits/64bits; adapted to our various types of spatial light modulator products.

2. Horizontal flip, vertical flip, grayscale flip, gamma correction, face correction and other image transformation functions support Chinese and English language switching.

3. Integrate a variety of specific light field control functions: such as diffractive light field, non-diffractive light field, structural light field.

4. Integrate more than twenty kinds of experimental projects, 35 Zernike polynomials, and support the superposition between phase diagrams.

5. Real-time online adjustment and control of all kinds of light field parameters.

6. Quickly correct the wavefront aberration according to the actual demand.

7. It can be extended independently and dynamically displayed in external input mode.

8. Autonomous selection of playback mode to realize high-speed refresh playback.

9. Green running mode without installation, directly unzip and run.
